PR-242

PLAN DETAILS

• 2 Storeys
• 4 Bedrooms
• Width: 21.5m
• Depth: 11.5m
• Building footprint area: 210m²
• 1 Living room
• 1 Dining room
• 1 Kitchen
• Open floor plan (Living, Dinning, Kitchen)
• 3 Baths/toilets
• 1 Store
• 1 Walk in closet for master bedroom
• 1 Balcony
• 2 Porches
• 1 Carport

ARCHITECTURAL DRAWINGS (INCLUDED)

• Floor plans and details
• Roof plan and details
• Elevations
• Sections
• Door and window schedules
• Septic tank and soak pit details

STRUCTURAL DRAWINGS (INCLUDED)

• Foundation layout and details
• Floor layout plans
• Floor slab reinforcement plans
• Roof layout and details
• Beam and Column details
• Slab details
• Staircase plan, section and details
• Other relevant structural drawings

Note: All drawings are delivered in A3 paper size and in PDF and DWG file format
