A Minimalist commercial building suitable for small commercial plots with provision for commercial space on ground floor and one bedroom apartments on upper floors.

$500 – $1,100

Clear

PLAN DETAILS

  • 3 Storeys
  • Width: 12.85m
  • Depth: 11.4m
  • Building footprint area: 122.15m2



  • Commercial Space on ground floor with wash rooms and a porch



  • Upper floors with four 1- bedroom apartments
  • 1 Bedroom @ Unit
  • 1 Living room @ Unit
  • 1 Kitchen @ Unit
  • 1 Bath/toilet @ Unit
  • 1 Balcony @ Unit



ARCHITECTURAL DRAWINGS (INCLUDED)

  • Floor plans and details
  • Roof plan and details
  • Elevations
  • Sections
  • Door and window schedules
  • Septic tank and soak pit details
  • 3D Documents
  • Other relevant details



STRUCTURAL DRAWINGS (INCLUDED)

  • Foundation layout and details
  • Floor slab layout plans
  • Floor slab reinforcement plans
  • Roof layout and details
  • Beam and Column details
  • Slab details
  • Staircase plan, section and details
  • Other relevant structural drawings
