PC-355

3 and 4 Bedroom units, 7 Storeys

$2,050$4,250

Clear
Want create site? Find Free WordPress Themes and plugins.

PLAN DETAILS

  • 7 Storeys
  • 6 3-bedroom units
  • 2 4-bedroom units
  • Width: 23.64m
  • Depth: 24.16m
  • Building footprint area: 426m2
  • 3 bedrooms @ 3-bedroom units
  • 2 baths/toilets @ 3-bedroom units
  • Only master bedroom self-contained for @ 3-bedroom units
  • 4 Balconies @ 3-bedroom units
  • 4 bedrooms @ 4-bedroom units
  • 5 baths/toilets @ 4-bedroom units
  • All bedrooms self-contained for @ 4-bedroom units
  • Office @ 4-bedroom units
  • Family room @ 4-bedroom units
  • 7 Balconies @ 4-bedroom units
  • 1 Living room @ unit
  • 1 Dining room @ unit
  • 1 Kitchen @ unit
  • 1 pantry @ unit
  • Open floor plan (Living, Dinning, Kitchen) @ unit
  • Walk in closet for master bedroom @ unit
  • Laundry room @unit
  • General Gym and Gym store
  • General Sauna
  • General Lounge and a bar
  • General wash rooms and dress rooms
  • Roof top accessible terrace
  • Elevator
  • Parking underneath the building



ARCHITECTURAL DRAWINGS (INCLUDED)

  • Floor plans and details
  • Roof plan and details
  • Elevations
  • Sections
  • Door and window schedules
  • Septic tank and soak pit details
  • Other relevant details



STRUCTURAL DRAWINGS (INCLUDED)

  • Foundation layout and details
  • Floor layout plans
  • Floor slab reinforcement plans
  • Roof layout and details
  • Beam and Column details
  • Slab details
  • Staircase plan, section and details
  • Other relevant structural drawings



Note: All drawings are delivered in A3 paper size and in PDF and DWG file format
