PC-350

PLAN DETAILS

• 3 Storeys
• 6 units
• 2 Bedroom units
• Width: 26.8m
• Depth: 12.8m
• Building footprint area: 317m²
• 1 Living room @ unit
• 1 Dining room @ unit
• 1 Kitchen @ unit
• Open floor plan (Living, Dinning, Kitchen) @ unit
• 2 Baths/toilets @ unit
• 1 Store @ unit
• 1 Walk in closet for master bedroom @ unit
• 4 Balconies

ARCHITECTURAL DRAWINGS (INCLUDED)

• Floor plans and details
• Roof plan and details
• Elevations
• Sections
• Door and window schedules
• Septic tank and soak pit details
• Other relevant details

STRUCTURAL DRAWINGS (INCLUDED)

• Foundation layout and details
• Floor layout plans
• Floor slab reinforcement plans
• Roof layout and details
• Beam and Column details
• Slab details
• Staircase plan, section and details
• Other relevant structural drawings

Note: All drawings are delivered in A3 paper size and in PDF and DWG file format
