PC-323
A Mixed apartment block design with 2-bedroom and 1-bedroom units (6-units total). It’s a minimalist design which is suitable for all those in real estate.
$550 – $1,000
PLAN DETAILS
- 3 Storeys
- 6 units total
- 2 Bedroom units (3No.)
- 1 Bedroom units (3No.)
- Width: 21.6m
- Depth: 13.7m
- Building footprint area: 187.95m2
- 1 Living room @ 2bedroom unit
- 1 Dining room @2bedroom unit
- 1 Kitchen @ 2bedroom unit
- Open floor plan (Living, Dinning) @ 2bedroom unit
- 2 Baths/toilets @2bedroom unit
- 1 Store @2bedroom unit
- 3 Balconies @ 2bedroom unit
- 1 Bedroom self-contained @2bedroom unit
- 1 Living room @ 1bedroom unit
- 1 Kitchen @ 1bedroom unit
- 1 Baths/toilets @1bedroom unit
- 2 Balconies @ 1bedroom unit
ARCHITECTURAL DRAWINGS (INCLUDED)
- Floor plans and details
- Roof plan and details
- Elevations
- Sections
- Door and window schedules
- Septic tank and soak pit details
- 3D Documents
- Other relevant details
STRUCTURAL DRAWINGS (INCLUDED)
- Foundation layout and details
- Floor layout plans
- Floor slab reinforcement plans
- Roof layout and details
- Beam and Column details
- Slab details
- Staircase plan, section and details
- Other relevant structural drawings
