PC-322
A Modern of 2-bedroom apartment block (6-units) with a 4-bedroom penthouse on the second floor (last floor). The penthouse is designed to give you that posh living with open terraces giving you captivating views.
$1,200 – $2,000
PLAN DETAILS
- 3 Storeys
- 6 units
- 2 Bedroom units
- Width: 42.9m
- Depth: 12.8m
- Building footprint area: 364.17m2
- 1 Living room @ unit
- 1 Dining room @ unit
- 1 Kitchen @ unit
- Open floor plan (Living, Dinning) @ unit
- 2 Baths/toilets @ unit
- 1 Store @ unit
- 2 Balconies @ unit
- 1 Bedroom self-contained
PENTHOUSE PLAN DETAILS
- 4 Bedrooms
- All Bedrooms self-contained
- 1 Living room
- 1 Dining room
- 1 Kitchen
- Open floor plan (Living, Dinning, Kitchen)
- 3 Baths/toilets
- 1 Powder room
- Pantry
- Family room
- Master bedroom ensuite with Walk in Closet
- 3 Balconies
ARCHITECTURAL DRAWINGS (INCLUDED)
- Floor plans and details
- Roof plan and details
- Elevations
- Sections
- Door and window schedules
- Septic tank and soak pit details
- 3D Documents
- Other relevant details
STRUCTURAL DRAWINGS (INCLUDED)
- Foundation layout and details
- Floor layout plans
- Floor slab reinforcement plans
- Roof layout and details
- Beam and Column details
- Slab details
- Staircase plan, section and details
- Other relevant structural drawings
