PC-230
An executive mixed apartment block design with a 4-bedroom house and 1-bedroom storeyed units (6-units total).
$750 – $1,300
PLAN DETAILS
- Width: 36.5m
- Depth: 15.3m
- Building footprint area: 501.3m2
4-Bedroom House
- 2 Storeys
- 1 unit total
- 4 Bedrooms
- 3 Bedrooms Self contained
- 1 Living room
- 1 Dining room
- 1 Kitchen
- Open floor plan
- 4 Baths/toilets
- 1 General toilet
- 2 Stores
- 2 Balconies
- 2 Porches
- 1 Family room
- 1 Office/Study room
- Morning Kitchen
- Walk in Closet for Master suite
1-Bedroom Units (Storeyed)
- 2 Storeys
- Private staircase
- 6 Units in total
- 1 Bedroom
- Living room
- 1 Dining room
- 1 Kitchen
- Open floor plan
- 1 Baths/toilets
- 1 General Toilet
- 1 Store
- 1 Balcony
- 1 Bedroom self-contained
- 2 Porches
ARCHITECTURAL DRAWINGS (INCLUDED)
- Floor plans and details
- Roof plan and details
- Elevations
- Sections
- Door and window schedules
- Septic tank and soak pit details
- 3D Documents
- Other relevant details
STRUCTURAL DRAWINGS (INCLUDED)
- Foundation layout and details
- Floor layout plans
- Floor slab reinforcement plans
- Roof layout and details
- Beam and Column details
- Slab details
- Staircase plan, section and details
- Other relevant structural drawings
